The AxN Series is a stand-alone device with B6 rectifier input in a range from 9 to 200A (continuous duty)
AxN Series signifies a complete current range between 4 Arms and 300 Arms across 6 sizes (AxM II, AxN, and AxW DC), alongside various interfaces including analogue (+/-10V), fieldbus (CANOpen and EtherCAT), pulse, and direction.
Featuring a comprehensive set of analogue and digital I/Os, AxN Series also offers a multiport encoder interface supporting popular digital protocols such as EnDat, Hiperface, SinCos, TTL, or resolver.
New AC drive AxN has been developed by Phase Motion Control and is the perfect partner for U3 brushless motors and for TK torque motors.
AxN 15.30.4 AxN 22.44.4 AxN 35.70.4 AxN 50.100.4 AxN 70.140.4 AxN 90.150.4 AxN 110.200.4
Rated Current Output 15A 22A 35A 50A 70A 90A 110A
Peak Current Output 30A 44A 70A 100A 140A 150A 200A
Main Power Supply
AC 150 ~ 500 Vac Three Phase
DC 0 ~ 800 Vdc
Auxiliary Power Supply
Voltage 24V ± 15%
Current 2A 3A 6A 8A
Brake Module Internal
Internal Brake Resistor 18Ω/60W 12Ω/60W 7Ω/60W 5Ω/60W 3.5Ω/60W 3.5Ω/150W 3Ω/150W
External Brake Resistor (Min/Max) 18Ω/18.4Ω 9Ω/13.8Ω 6Ω/7.9Ω 4.5Ω/5.5Ω 2.1Ω/4Ω 2Ω/3.7Ω 2Ω/2.7Ω
Fieldbus Support CANOpen – EtherCAT – Modbus
Position Sensor Support SinCos Encoder, Endat Encoder, Digital Incremental with Hall, Resolver and Hiperface Encoder
Safety STO (Safe Torque Off) complies with SIL3 IEC EN 61800-5-2:2007
Management software Phase Tools suite (free download from company web site)
